HYDRAULIC FILTER SPIN ON
PFH55176
HYDRAULIC FILTER SPIN ON
PFH55176
£35.84 exc VAT
In stock
In stock
Order By 2pm for UK Free Next Day Delivery
Orders under £250 Standard Delivery £25 +VAT
Orders over £250 Free Delivery
| Product Specification | |
| Thread Size | 13/16 x 16 UN |
| Outer Diameter | 78 mm (3.07 inch) |
| Gasket OD | 69 mm (2.72 inch) |
| Gasket ID | 59 mm (2.32 inch) |
| Length | 138 mm (5.43 inch) |
| Overall Length | 138 mm (5.43 inch) |
| Anti Drain Back Valve | No |
| Anti Syphon | No |
| Bypass Valve | Yes |
| Bypass Valve Setting LR | NA |
| Bypass Valve Setting HR | 2.5 bar 35 psi |
| Efficiency 50% Beta 2 | 5 micron |
| Efficiency 99.9% Beta 1000 | 23 micron |
| Efficiency Test Standard | ISO IATF 16949 |
| Stand Pipe | No |
| Type | OEM Quality Hydraulic Filter |
| Style | Hydraulic Spin On |
| Media Type | Synthetic Pleated |
| Notes | Bottom End Closed |
| Notes | Gasket Seal Included |
| Notes | Square Seal is Attached |
| Notes | |
| Primary Application | CATERPILLAR 4717003 |
OEM Cross Reference
| Manufacturer Name | Manufacturer Part No |
| AC DELCO | PF2160 |
| AC DELCO | PF1739 |
| ALCO | SP1445 |
| AMERICAN PARTS | 92209 |
| AMERICAN PARTS | 92479 |
| AMERICAN PARTS | 91025 |
| ASAS | SP843 |
| ASAS FILTER | SP843 |
| AVELING BARFORD | ABP3002065 |
| BALDWIN | BT8417 |
| BALDWIN | BT9402 |
| BALDWIN | BT8439MPG |
| BENFORD | 8009050 |
| BIG A | 91025 |
| BIG A | 91116 |
| CARQUEST | 84025 |
| CARQUEST | 84116 |
| CASE IH | 85817004 |
| CASE IH | 9968353 |
| CASE IH | 9969450 |
| CASE IH | 8434800 |
| CATERPILLAR | 1194740 |
| CATERPILLAR | 4476968 |
| CATERPILLAR | 4717003 |
| CATERPILLAR | 6E0924 |
| COMPAIR | GB6050047 |
| DONALDSON | P550486 |
| DONALDSON | P551324 |
| EAGLE PICHER | 57299 |
| FAI FILTRI | CSP01513P10A |
| FIAT | 119936862 |
| FIAT ALLIS | 119936862 |
| FIL FILTER | ZP3215 |
| FLEETGUARD | HF35467 |
| FLEETGUARD | HF28853 |
| FLEETGUARD | HF35375 |
| FLEETRITE | HFR828853 |
| HIDROMEK | F0315803 |
| PARKER HANNIFIN | 900283Q20Q |
| PARKER HANNIFIN | 944055Q |
| FLUITEK | FLK1800363 |
| FORD | 85817004 |
| GRAINGER | 2KZF6 |
| GREYFRIARS | HS7637 |
| GREYFRIARS | HS7657 |
| GREYFRIARS | HS7697 |
| HASTINGS | HF973 |
| HENGST | HG353WD |
| HIFI FILTER | SH70014 |
| KALMAR | 119210 |
| KRALINATOR | L7116 |
| LUBER FINER | LFH8876 |
| LUBER FINER | LFH88761 |
| LUBER FINER | LFP2275 |
| LUBER FINER | LFP22751 |
| MANITOU | 189195 |
| MANITOU | 561749 |
| MANITOU | 943911 |
| MANN HUMMEL | WD7245 |
| MASSEY FERGUSON | 3621299M1 |
| MASSEY FERGUSON | 6190164M1 |
| MATCH FILTER | 112995 |
| MATCH FILTER | 12632 |
| MATCH FILTER | 4301125 |
| MISFAT | Z657 |
| NAPA | 7025 |
| NAPA GOLD | 7025 |
| NAPA GOLD | 7116 |
| NEW HOLLAND | 9968353 |
| NEW HOLLAND | 9969450 |
| NEW HOLLAND | 85817004 |
| NEW HOLLAND | 8434800 |
| OEM | A860225 |
| PALLMAN | PFH55176 |
| PALLMAN FILTER | PFH55176 |
| PARKER HANNIFIN | BT8417 |
| PARKER HANNIFIN | BT9402 |
| PUROLATOR | L25100 |
| SAKURA | TC5501 |
| SF FILTER | SPH9900 |
| SF FILTER | SPH9842 |
| SF FILTER | SPH94078 |
| SPAREX | S109203 |
| SPAREX | S109606 |
| SPERRY NEW HOLLAND | 85817004 |
| SPERRY NEW HOLLAND | 9969450 |
| SURE FILTER | SFT8417 |
| TECHNICAL FILTRATION LTD | BSH6337 |
| TEREX | 6190810M1 |
| TORQUIP | 9968353 |
| TOTAL SOURCE | 112995 |
| TOTAL SOURCE | CT6E0924 |
| TRP | 1535356 |
| TRP DAF | 1535356 |
| TVH | 12632 |
| UFI FILTER | 8600100 |
| VMC | HF550486 |
| WIX FILTER | 57116 |
| WIX FILTER | 57004R |
| WIX FILTER | 557025 |
| WIX FILTER | 57025 |
| CATERPILLAR | 4476968 |
| WOODGATE | WGH1927B |
Machinery & Equipment
| Equipment | Year | Equipment Type | Equipment Options | Engine |
| CATERPILLAR 414E | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054C | |
| CATERPILLAR 416 | BACKHOE LOADER | 400 SERIES | PERKINS 4.236 | |
| CATERPILLAR 416 II | BACKHOE LOADER | 400 SERIES | PERKINS 4.236 | |
| CATERPILLAR 416B | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054 | |
| CATERPILLAR 416C | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054 | |
| CATERPILLAR 416D | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054B | |
| CATERPILLAR 416E | BACKHOE LOADER | 400 SERIES | CATERPILLAR C4.4 | |
| CATERPILLAR 420D | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054C | |
| CATERPILLAR 420D | BACKHOE LOADER | CATERPILLAR 3054T | ||
| CATERPILLAR 420E | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054C | |
| CATERPILLAR 420E | BACKHOE LOADER | CATERPILLAR C4.4T | ||
| CATERPILLAR 420E IT | BACKHOE LOADER | CATERPILLAR C4.4T | ||
| CATERPILLAR 422E | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054C | |
| CATERPILLAR 424D | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054B | |
| CATERPILLAR 426 | BACKHOE LOADER | 400 SERIES | PERKINS 4.236 | |
| CATERPILLAR 426 II | BACKHOE LOADER | 400 SERIES | PERKINS 4.236 | |
| CATERPILLAR 426B | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054 | |
| CATERPILLAR 426C | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054T | |
| CATERPILLAR 428 | BACKHOE LOADER | 400 SERIES | PERKINS 4.236 | |
| CATERPILLAR 428 II | BACKHOE LOADER | 400 SERIES | PERKINS 4.236 | |
| CATERPILLAR 428B | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054 | |
| CATERPILLAR 428C | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054 | |
| CATERPILLAR 428D | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054T | |
| CATERPILLAR 428DNF | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054T | |
| CATERPILLAR 428E | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054C | |
| CATERPILLAR 430D | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054T | |
| CATERPILLAR 430E | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054C | |
| CATERPILLAR 430E | BACKHOE LOADER | CATERPILLAR C4.4T | ||
| CATERPILLAR 432D | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054T | |
| CATERPILLAR 432E | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054C | |
| CATERPILLAR 434E | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054C | |
| CATERPILLAR 436 | BACKHOE LOADER | 400 SERIES | PERKINS 4.236 | |
| CATERPILLAR 436 II | BACKHOE LOADER | 400 SERIES | PERKINS 4.236 | |
| CATERPILLAR 436B | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054 | |
| CATERPILLAR 436C | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054T | |
| CATERPILLAR 438 | BACKHOE LOADER | 400 SERIES | PERKINS 4.236 | |
| CATERPILLAR 438 II | BACKHOE LOADER | 400 SERIES | PERKINS 4.236 | |
| CATERPILLAR 438B | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054T | |
| CATERPILLAR 438C | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054 | |
| CATERPILLAR 438D | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054T | |
| CATERPILLAR 442D | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054T | |
| CATERPILLAR 442E | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054C | |
| CATERPILLAR 444E | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3054C | |
| CATERPILLAR 446 | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3114 | |
| CATERPILLAR 446B | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3114T | |
| CATERPILLAR 446D | BACKHOE LOADER | 400 SERIES | CATERPILLAR 3114T | |
| CATERPILLAR 450E | BACKHOE LOADER | 400 SERIES | CATERPILLAR C4.4TAACERT | |
| CATERPILLAR R40 | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR R60 | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR R80 | FORKLIFT | 1KK | PERKINS 4.236 | |
| CATERPILLAR R81 | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR RC60 | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR RT40 | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR RT60 | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR RTC60 | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR T100D | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR T100D | FORKLIFT | PERKINS 4.248.2 | ||
| CATERPILLAR T150D | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR T150D | FORKLIFT | PERKINS 4.248.2 | ||
| CATERPILLAR T25 | FORKLIFT | CONTINENTAL F163 | ||
| CATERPILLAR T25D | FORKLIFT | PEUGEOT XN1P | ||
| CATERPILLAR T30B | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR T30C | FORKLIFT | PERKINS 4.203.2 | ||
| CATERPILLAR T30C | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR T40D | FORKLIFT | PEUGEOT XD3P | ||
| CATERPILLAR T40D | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR T40D | FORKLIFT | PEUGEOT XN1P | ||
| CATERPILLAR T60 | FORKLIFT | PERKINS 3.152 | ||
| CATERPILLAR T60B | FORKLIFT | PERKINS 3.152 | ||
| CATERPILLAR T60C | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR T60D | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR T60D | FORKLIFT | PERKINS 4.2482 | ||
| CATERPILLAR T60DSA | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR TC120D | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR TC120D | FORKLIFT | PERKINS 4.2482 | ||
| CATERPILLAR TC30 | FORKLIFT | CONTINENTAL F163 | ||
| CATERPILLAR TC40D | FORKLIFT | PEUGEOT XN1P | ||
| CATERPILLAR TC60C | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR TC60C | FORKLIFT | PERKINS 4.2032 | ||
| CATERPILLAR TC60D | FORKLIFT | PEUGEOT XN1P | ||
| CATERPILLAR TC60D | FORKLIFT | PEUGEOT XD3P | ||
| CATERPILLAR TC60DSA | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR TH514D | TELEHANDLER | CATERPILLAR C3.4B | ||
| CATERPILLAR V100 | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V100F | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V100F | FORKLIFT | PERKINS 4.248.2 | ||
| CATERPILLAR V110B | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V150 | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V155B | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V25D | FORKLIFT | PEUGEOT XN1P | ||
| CATERPILLAR V25D | FORKLIFT | PEUGEOT XD3P | ||
| CATERPILLAR V30C | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V30C | FORKLIFT | CONTINENTAL F227 | ||
| CATERPILLAR V30C | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR V30C | FORKLIFT | PERKINS 4.2032 | ||
| CATERPILLAR V40C | FORKLIFT | PERKINS 4.203.2 | ||
| CATERPILLAR V40D | FORKLIFT | PERKINS 4.203.2 | ||
| CATERPILLAR V40D | FORKLIFT | PEUGEOT XN1P | ||
| CATERPILLAR V40D | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR V40D | FORKLIFT | PEUGEOT XD3P | ||
| CATERPILLAR V60 | FORKLIFT | PERKINS 3152 | ||
| CATERPILLAR V60B | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V60C | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V60D | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V60E | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V70F | FORKLIFT | PERKINS 4.248.2 | ||
| CATERPILLAR V70F | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V80F | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V90E | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR V90F | FORKLIFT | PERKINS 4.2482 | ||
| CATERPILLAR V90F | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR VC110F | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR VC110F | FORKLIFT | PERKINS 4.248.2 | ||
| CATERPILLAR VC40D | FORKLIFT | PEUGEOT XD3P | ||
| CATERPILLAR VC40D | FORKLIFT | PEUGEOT XN1P | ||
| CATERPILLAR VC60C | FORKLIFT | PERKINS 4.236 | ||
| CATERPILLAR VC60C | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR VC60C | FORKLIFT | CONTINENTAL F227 | ||
| CATERPILLAR VC60C | FORKLIFT | PERKINS 4.2032 | ||
| CATERPILLAR VC60D | FORKLIFT | PEUGEOT XD3P | ||
| CATERPILLAR VC60D | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR VC60D | FORKLIFT | PEUGEOT XN1P | ||
| CATERPILLAR VC60D | FORKLIFT | PERKINS 4.203.2 | ||
| CATERPILLAR VC60DSA | FORKLIFT | CATERPILLAR 1404 | ||
| CATERPILLAR VC60DSA | FORKLIFT | PERKINS 4.2032 | ||
| FIAT KOBELCO B100 | BACKHOE LOADER | PERKINS 4.2032 | ||
| MANITOU ML 635 TURBO | 2003 | TELEHANDLER | ML SERIES | PERKINS 1104C44T |
| MANITOU MLT 1035 L LSU | 2003 | TELEHANDLER | MLT SERIES TURBO | PERKINS 1104D44TA |
| MANITOU MLT 634 120 LSU | 2003 | TELEHANDLER | MLT SERIES | PERKINS 1104 DE44TA |
| MANITOU MLT 634 120 LSU | 2003 | TELEHANDLER | MLT SERIES POWERSHIFT | PERKINS 1104 DE44TA |
| MANITOU MLT 634 TURBO LSU | 2003 | TELEHANDLER | MLT SERIES | PERKINS 1104D44TA |
| MANITOU MLT 735 120 LSU | 2003 | TELEHANDLER | MLT SERIES | PERKINS 1104 DE44TA |
| MANITOU MLT 735 120 LSU | 2003 | TELEHANDLER | MLT SERIES POWERSHIFT | PERKINS 1104 DE44TA |
| MANITOU MLT 735 TURBO LSU | 2003 | TELEHANDLER | MLT SERIES | PERKINS 1104D44TA |
| MANITOU MLT 741 120 LSU | 2003 | TELEHANDLER | MLT SERIES | PERKINS 1104 DE44TA |
| MANITOU MLT 741 120 LSU | 2003 | TELEHANDLER | MLT SERIES POWERSHIFT | PERKINS 1104 DE44TA |
| MANITOU MLT 741 TURBO LSU | 2003 | TELEHANDLER | MLT SERIES | PERKINS 1104D44TA |
| MANITOU MRT2145 | TELEHANDLER | MRT SERIES | PERKINS 1004.40T | |
| MANITOU MT 1235 S | 2006 | TELEHANDLER | MT SERIES | PERKINS 1104C44 |
| MANITOU MT 1235 S TURBO | 2006 | TELEHANDLER | MT SERIES | PERKINS 1104C44T |
| MANITOU MT 1240 L TURBO | 2010 | TELEHANDLER | MT SERIES | PERKINS 1104C44T |
| MANITOU MT 1240 L TURBO | 2003 | TELEHANDLER | MT SERIES ULTRA | PERKINS 1104C44T |
| MANITOU MT 1335 SL | 2003 | TELEHANDLER | MT SERIES | PERKINS 1104C44 |
| MANITOU MT 1335 SL TURBO | 2003 | TELEHANDLER | MT SERIES | PERKINS 1104C44T |
| MANITOU MT 1340 SL TURBO | 2003 | TELEHANDLER | MT SERIES | PERKINS 1104C44T |
| MANITOU MT 1340 SL TURBO | 2003 | TELEHANDLER | MT SERIES ULTRA | PERKINS 1104C44T |
| MANITOU MT 1435 SL | 2006 | TELEHANDLER | MT SERIES | PERKINS 1104C44 |
| MANITOU MT 1435 SL TURBO | 2006 | TELEHANDLER | MT SERIES | PERKINS 1104C44T |
| MANITOU MT 1440 SL | 2006 | TELEHANDLER | MT SERIES | PERKINS 1104C44 |
| MANITOU MT 1440 SL TURBO | 2006 | TELEHANDLER | MT SERIES | PERKINS 1104C44T |
| MANITOU MT 1440 SL TURBO | 2003 | TELEHANDLER | MT SERIES ULTRA | PERKINS 1104C44T |
| MANITOU MT 1740 SL TURBO | 2003 | TELEHANDLER | MT SERIES | PERKINS 1104C44T |
| MANITOU MT 1740 SL TURBO | 2003 | TELEHANDLER | MT SERIES ULTRA | PERKINS 1104C44T |
| MANITOU MT 940 L TURBO | 2003 | TELEHANDLER | MT SERIES | PERKINS 1104C44T |
| MANITOU MT1030SS2 | TELEHANDLER | PERKINS 1104C44T | ||
| MANITOU MT1235 | TELEHANDLER | MT SERIES | PERKINS 1104C44T | |
| NEW HOLLAND 555E | BACKHOE LOADER | IVECO 445TA M3 | ||
| NEW HOLLAND B100B | BACKHOE LOADER | IVECO 445TA M3 | ||
| NEW HOLLAND B100B | BACKHOE LOADER | IVECO 445TA EEA | ||
| NEW HOLLAND B100BLR | BACKHOE LOADER | IVECO 445TA EEA | ||
| NEW HOLLAND B90B | BACKHOE LOADER | IVECO 445TA M3 | ||
| NEW HOLLAND B90BLR | BACKHOE LOADER | IVECO 445TA ML5 | ||
| NEW HOLLAND LB110 | BACKHOE LOADER | LB SERIES | NEW HOLLAND BSD450T | |
| NEW HOLLAND LB75 | BACKHOE LOADER | LB SERIES | NEW HOLLAND 445T M2 | |
| NEW HOLLAND LB75B | BACKHOE LOADER | LB SERIES | NEW HOLLAND 445T M2 | |
| NEW HOLLAND LB90 | BACKHOE LOADER | LB SERIES | NEW HOLLAND BSD450T | |
| NEW HOLLAND LB90B | BACKHOE LOADER | LB SERIES | IVECO F4G E0454C D | |
| NEW HOLLAND LB90B | BACKHOE LOADER | LB SERIES | IVECO 445TA M2 | |
| NEW HOLLAND NH75TLB | BACKHOE LOADER | IVECO 445TA M2 | ||
| TOWMOTOR T60 | FORKLIFT | T SERIES | IVECO 445TA M2 | |
| TOWMOTOR T60D | FORKLIFT | T SERIES | IVECO 445TA M2 | |
| TOWMOTOR TC60C | FORKLIFT | TC SERIES | IVECO 445TA M2 |
